Standard Features
Features for “MDX12BP10K”
- Length: 12‘
- Width: 77“
- Deck Height: 24“
- GVWR: 10,000 lbs.
- GAWR: 5,200 lbs.
- Empty Weight: 3,460 lbs.
- Load Capacity: 7,521 lbs.
- Main Frame: 5″ Channel Frame
- Cross-Bracing: 4″ x 3″ x 3/16″ Tubing
- Dump Bed Width: 77″
- Side Height: 19″
- Capacity: 4.3 Cubic Yards
- Side Walls: 12G Formed Plate
- Side Rail: 12G Formed Plate
- Side Post: 12G Formed Plate
- Flooring: 10G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 5′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 5″ x 16″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 7,000 lb. Side Wind Jack
- Tool Box: Integrated In Tongue
- Suspension: Leaf Spring
- Axles: 2 – 5,200 lb. Electric Brake Axles
- 8 Ply ST225/75R15 Tires
- 15″ Black Mod Steel Wheels
- Bolt Pattern: 6 on 5.5
- Safety Chains: 1/4″ Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
MDX 3D
Standard Features
Features for “MDX12BP10K”
- Length: 12‘
- Width: 77“
- Deck Height: 24“
- GVWR: 10,000 lbs.
- GAWR: 5,200 lbs.
- Empty Weight: 3,460 lbs.
- Load Capacity: 7,521 lbs.
- Main Frame: 5″ Channel Frame
- Cross-Bracing: 4″ x 3″ x 3/16″ Tubing
- Dump Bed Width: 77″
- Side Height: 19″
- Capacity: 4.3 Cubic Yards
- Side Walls: 12G Formed Plate
- Side Rail: 12G Formed Plate
- Side Post: 12G Formed Plate
- Flooring: 10G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 5′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 5″ x 16″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 7,000 lb. Side Wind Jack
- Tool Box: Integrated In Tongue
- Suspension: Leaf Spring
- Axles: 2 – 5,200 lb. Electric Brake Axles
- 8 Ply ST225/75R15 Tires
- 15″ Black Mod Steel Wheels
- Bolt Pattern: 6 on 5.5
- Safety Chains: 1/4″ Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
MDX
The Mid-Size Dump Trailer That Delivers More
Prime
When you need a dump trailer that balances size, strength, and versatility, the RawMaxx MDX steps in. Compact enough for tighter jobsites yet tough enough for demanding hauls, the MDX is built to move material with ease. With a GVWR of 14,000 lbs. and over 10,000 lbs. of load capacity, it’s the perfect balance of power and practicality.
Engineered on a rugged I-beam frame with heavy-duty cross-members, the MDX combines durability with smart design. Its 10-gauge steel sides, reinforced posts, and one-piece steel floor are ready for whatever the day throws at it — from gravel and debris to equipment and pallets.
The hydraulic scissor lift system gives the MDX controlled, efficient dumping performance. Pair that with an easy-to-use 3-way rear gate and slide-in loading ramps, and you have a trailer that’s as versatile as the jobs you take on.
Safety and reliability are built into every detail. From the 2-5/16” adjustable coupler and dual 10,000 lb. jacks to DOT-approved LED lighting, G70 safety chains, and a marine deep-cycle battery with integrated charger, the MDX is ready to work as hard as you do. Radial ST235/80R16 tires and a slipper spring suspension keep every load moving smoothly.
And because every job is different, RawMaxx gives you the power of customization. Taller sides, removable extensions, hydraulic jacks, wireless remote controls, and two-tone paint upgrades make it easy to tailor the MDX to your workflow.
The RawMaxx MDX — tough, versatile, and always ready for the next load.
