Standard Features
Features for “LTX16BP20K”
- Length: 16‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 5,900 lbs.
- Load Capacity: 16,215 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 20″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
Features for “LTX18BP20K”
- Length: 18‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 7,187 lbs.
- Load Capacity: 14,735 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 30″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
Features for “LTX20BP20K”
- Length: 20‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 7,350 lbs.
- Load Capacity: 14,548 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 30″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
LTX BP 3D
Standard Features
Features for “LTX16BP20K”
- Length: 16‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 5,900 lbs.
- Load Capacity: 16,215 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 20″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
Features for “LTX18BP20K”
- Length: 18‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 7,187 lbs.
- Load Capacity: 14,735 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 30″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
Features for “LTX20BP20K”
- Length: 20‘
- Width: 83“
- Deck Height: 28“
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 7,350 lbs.
- Load Capacity: 14,548 lbs.
- Main Frame: 10″ x 15 lb. I Beam
- Cross-Bracing: 4″ x 6″ x 3/16″ Tubing
- Dump Bed Width: 83″
- Side Height: 24″
- Capacity: 7.45 Cubic Yards
- Side Walls: 10G Formed Plate
- Side Rail: 10G Formed Plate
- Side Post: 10G Formed Plate
- Flooring: 7G Plate
- Fenders: 12G Diamond Plate Fenders
- D-Rings: 4 D-Rings Standard (Welded Inside Corners)
- State Pockets: 3 7/8″ x 1 13/16″ (ID)
- Rear Gate: 3in1 Rear Gate
- Latching System: EZ Slam Door Latches
- Ramps: 6′ Slide Out Channel Ramps
- Tarp: Manual Tarp Kit
- Lift System: Hydraulic Power up / Down
- Pump: KTI Hydraulic Pump
- Scissor: 6″ x 30″ Cylinder Hoist
- Tilt Angle: 41°
- Coupler: 2 5/16″ Adjustable Ball
- Jacks: 10,000 lb. Side Wind Drop Leg Jack
- Tool Box: Integrated In Tongue
- Suspension: Torsion
- Axles: 2 – 10,000 lb. Electric Brake Axles
- 18 Ply ST235/75R17.5 Tires
- 17.5″ Black Mod Steel Wheels
- Bolt Pattern: 8 on 6.5″
- Safety Chains: 3/8″ G70 Chains
- Spare Mount: Included
- All Weather Proof Harness
- Market Lights: 3/4″ LED Bullet Lights
- Rear Lights: 6″ Oval DOT Approved LED Lights
- Paint: Powder Coated
- Color: Midnight Black With Classic Orange Trim
- 5 Year Dexter Axle Warranty
- 3 Year Structural Warranty
- 1 Year Paint Warranty
LTX BP
Relentless
The Bumper Pull Dump Built to Carry Real Weight
When you need heavy-duty dump performance without stepping up to a gooseneck, the RawMaxx LTX BP delivers serious capability in a bumper pull platform. Available in multiple lengths and rated at 20,000 lbs. GVWR (model dependent), the LTX BP offers the strength and durability contractors demand — with the simplicity and versatility of a bumper pull connection.
Built on a heavy I-beam main frame with reinforced cross-members and a rigid dump bed structure, the LTX BP is designed to handle tough material loads day after day. A 7-gauge one-piece steel floor and 10-gauge formed side walls create a bed that stands up to rock, debris, demolition waste, and equipment without compromise.
Power up / power down hydraulics driven by a KTI 12V pump and heavy-duty scissor lift provide strong, controlled dumping with a high dump angle for clean material release. The 3-way rear gate with EZ Slam latches and slide-in ramps give you flexibility to dump, spread, or load equipment from a single trailer.
Dual heavy-duty axles, electric brakes, and radial tires provide road stability under serious weight, while LED lighting, all-weather wiring, G70 safety chains, and an integrated battery charging system come standard.
Available upgrades — including hydraulic jacks, side height options, remote control, tarp systems, and axle packages — allow you to spec the LTX BP for your exact jobsite demands.
The RawMaxx LTX BP — bumper pull convenience with heavy-duty backbone, built to move real material without backing down.
