Handle

LPX Telescopic

Available Sizes

Trailer Specs

Dimensions

Length: 12'
Width: 83"
Deck Height: 28"

Weight Rating

GVWR: 14,000 lbs.
GAWR: 7,000 lbs.
Empty Weight: 5,144 lbs.
Load Capacity: 10,184 lbs.

Finish

Type: Powder Coat
Prep: Grit Blast
Standard Color: Jet Black

Warranty

Axle: 5 Year Dexter
Trailer: 3 Year Structural / 1 Year Paint

Tongue

Coupler

Coupler: 2-5/16” Adjustable Ball Coupler

Jacks

Jack: 1 - 10,000 lbs. Side Wind Drop Leg

Tool Box

Tongue Tool Box: Mega Boxx for Pump, Battery & Charger

Tongue

Tongue: 8" x 13 lb. I-beam
Tongue Length: 65"

Safety System

Safety Chains: 3/8" G70 Safety Chains
Breakaway System: Electric Breakaway Kit
Reflective Tape: 3M DOT Compliant Reflective Tape

Chassis

Frame

Main Frame: 8" x 13 lb. I-beam Frame
Cross-Member: 4" x 6" x 3/16" Tubing
Side Step: 12G formed plate located at the front on both sides

Dump Bed

Tilt Frame

Type: 5' x 5" x 3/8" Angle
Cross-Members: 3" Channel / 16" on Center

Dump Bed

Inside Width: 83"
Side Height: 22"
Side Walls: 10G Formed Walls
Flooring: 7G Floor
Fenders: 12G Diamond Plate Steel
D-Rings: 4 D-Rings (Welded Inside Corners)
Side Posts: 10G formed plate (3 per side)
Stake Pockets: 10G formed plate (3 per side)
Side Rail: 10G formed plate
Spare Tire Mount: Located at front Passenger Side Wall

Cargo Capacity:

5.89 Cubic Yards

Rear Gate

Gate: 3-1 Rear Gate
Latching System: EZ Slam Door Latches
Ramps: 6' Slide-Out Channel Ramps

Lift System

Power: Hydraulic - Power Up - Gravity Down
Pump: KTI 12V Hydraulic Pump
Controller: 14' Cable with Control
Telescopic: 3 Stage - 120" Cylinder
Tilt Angle: 44°

Tarp

Manual Tarp Kit

Running Gear

Tires

Type: Radial Tires
Size: ST235/80R16
Ply: 10 Ply
Rating: 3,520 lbs.
Rims: 16” Black Mod Wheels
Bolt Pattern: 8 on 6.5”

Suspension

Axle Type: Spring
Axles: 2
Rating: 7,000 lbs.
Brakes: Electric

Electrical & Lighting

Wiring

Front Plug: 7 - Way Plug
Frame Wiring: All Weather Wiring Harness

Lighting

Side Markers: 3/4" LED Bullet Lights
Rear Lights: DOT Approved LED Lights

Battery & Charging

Battery: 27M Deep Cycle Marine Battery
Charging System: 110V Integrated Trickle Charger

Available Upgrades

Axle Upgrades

Tire Upgrades

Spare Tire Options

Side Height Options

Removable Extensions

Jack Options

Paint Upgrades

Other Options

Trailer Specs

Dimensions

Length: 14'
Width: 83"
Deck Height: 28"

Weight Rating

GVWR: 14,000 lbs.
GAWR: 7,000 lbs.
Empty Weight: 5,414 lbs.
Load Capacity: 9,873 lbs.

Finish

Type: Powder Coat
Prep: Grit Blast
Standard Color: Jet Black

Warranty

Axle: 5 Year Dexter
Trailer: 3 Year Structural / 1 Year Paint

Tongue

Coupler

Coupler: 2-5/16” Adjustable Ball Coupler

Jacks

Jack: 1 - 10,000 lbs. Side Wind Drop Leg

Tool Box

Tongue Tool Box: Mega Boxx for Pump, Battery & Charger

Tongue

Tongue: 8" x 13 lb. I-beam
Tongue Length: 65"

Safety System

Safety Chains: 3/8" G70 Safety Chains
Breakaway System: Electric Breakaway Kit
Reflective Tape: 3M DOT Compliant Reflective Tape

Chassis

Frame

Main Frame: 8" x 13 lb. I-beam Frame
Cross-Member: 4" x 6" x 3/16" Tubing

Dump Bed

Tilt Frame

Type: 5' x 5" x 3/8" Angle
Cross-Members: 3" Channel / 16" on Center

Dump Bed

Inside Width: 83"
Side Height: 19"
Side Walls: 10G Formed Walls
Flooring: 7G Floor
Fenders: 12G Diamond Plate Steel
D-Rings: 4 D-Rings (Welded Inside Corners)
Side Posts: 10G formed plate (4 per side)
Stake Pockets: 10G formed plate (5 per side)
Side Rail: 10G formed plate

Cargo Capacity:

6.85 Cubic Yards

Rear Gate

Gate: 3-1 Rear Gate
Latching System: EZ Slam Door Latches
Ramps: 6' Slide-Out Channel Ramps

Lift System

Power: Hydraulic - Powder Up - Gravity Down
Pump: KTI 12V Hydraulic Pump
Controller: 14' Cable with Control
Scissor: 3 Stage - 120" Cylinder
Tilt Angle: 44°

Tarp

Manual Tarp Kit

Running Gear

Tires

Type: Radial Tires
Size: ST235/80R16
Ply: 10 Ply
Rating: 3,520 lbs.
Rims: 16” Black Mod Wheels
Bolt Pattern: 8 on 6.5”

Suspension

Axle Type: Spring
Axles: 2
Rating: 7,000 lbs.
Brakes: Electric

Electrical & Lighting

Wiring

Front Plug: 7 - Way
Frame Wiring: All Weather Wiring Harness

Lighting

Side Markers: 3/4" LED Bullet Lights
Rear Lights: DOT Approved LED Lights

Battery & Charging

Battery: 27M Deep Cycle Marine Battery
Charging System: 110V Integrated Trickle Charger

Available Upgrades

Axle Upgrades

Tire Options

Spare Tire Upgrades

Side Height Options

Removable Extensions

Jack Upgrades

Paint Upgrades

Other Options

Trailer Specs

Dimensions

Length: 16'
Width: 83"
Deck Height: 28"

Weight Rating

GVWR: 14,000 lbs.
GAWR: 7,000 lbs.
Empty Weight: 5,896 lbs.
Load Capacity: 9,319 lbs.

Finish

Type: Powder Coat
Prep: Grit Blast
Standard Color: Jet Black

Warranty

Axle: 5 Year Dexter
Trailer: 3 Year Structural / 1 Year Paint

Tongue

Coupler

Coupler: 2-5/16” Adjustable Ball Coupler

Jacks

Jack: 1 - 10,000 lbs. Side Wind Drop Leg

Tool Box

Tongue Tool Box: Mega Boxx for Pump, Battery & Charger

Tongue

Tongue: 8" x 13 lb. I-beam
Tongue Length: 65"

Safety System

Safety Chains: 3/8" G70 Safety Chains
Breakaway System: Electric Breakaway Kit
Reflective Tape: 3M DOT Compliant Reflective Tape

Chassis

Frame

Main Frame: 8" x 13 lb. I-beam Frame
Cross-Member: 4" x 6" x 3/16" Tubing

Dump Bed

Tilt Frame

Type: 5' x 5" x 3/8" Angle
Cross-Members: 3" Channel / 16" on Center

Dump Bed

Inside Width: 83"
Side Height: 22"
Flooring: 7G Floor
Side Walls: 10G Formed Walls
Fenders: 12G Diamond Plate Steel
D-Rings: 4 D-Rings (Welded Inside Corners)
Side Posts: 10G formed plate (4 per side)
Stake Pockets: 10G formed plate (5 per side)
Side Rail: 10G formed plate

Cargo Capacity:

9.5 Cubic Yards

Rear Gate

Gate: 3-1 Rear Gate
Latching System: EZ Slam Door Latches
Ramps: 6' Slide-Out Channel Ramps

Lift System

Power: Hydraulic - Power Up - Gravity Down
Pump: KTI 12V Hydraulic Pump
Controller: 14' Cable with Control
Scissor: 3 Stage - 120" Cylinder
Tilt Angle: 44°

Tarp

Manual Tarp Kit

Running Gear

Tires

Type: Radial Tires
Size: ST235/80R16
Ply: 10 Ply
Rating: 3,520 lbs.
Rims: 16” Black Mod Wheels
Bolt Pattern: 8 on 6.5”

Suspension

Axle Type: Spring
Axles: 2
Rating: 7,000 lbs.
Brakes: Electric

Electrical & Lighting

Wiring

Front Plug: 7 - Way
Frame Wiring: All Weather Wiring Harness

Lighting

Side Markers: 3/4" LED Bullet Lights
Rear Lights: DOT Approved LED Lights

Battery & Charging

Battery: 27M Deep Cycle Marine Battery
Charging System: 110V Integrated Trickle Charger

Available Upgrades

Axle Upgrades

Tire Upgrades

Spare Tire Upgrades

Side Height Options

Removable Extensions

Jack Options

Paint Upgrades

Other Options

Handle

360° View

Available Colors

Jet Black Shadow Gray Lava Gray Ghost White Chalk White Sunny Beige Desert Tan Army Green Limon Green Cobalt Blue Classic Orange Ruby Red
