Standard Features

Features for “HTX30GN20K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,348 lbs.
Load Capacity: 13,315 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN20K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 8,780 lbs.
Load Capacity: 14,025 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN20K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 8,920 lbs.
Load Capacity: 13,850 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN20K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,060 lbs.
Load Capacity: 13,675 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN20K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,200 lbs.
Load Capacity: 13,500 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN20K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,340 lbs.
Load Capacity: 13,325 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN20K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,480 lbs.
Load Capacity: 13,150 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN20K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,620 lbs.
Load Capacity: 12,975, lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX30GN24K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,348 lbs.
Load Capacity: 17,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN24K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,550 lbs.
Load Capacity: 18,315 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN24K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,650 lbs.
Load Capacity: 17,938 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN24K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,750 lbs.
Load Capacity: 17,813 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN24K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,825 lbs.
Load Capacity: 17,719 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN24K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,075 lbs.
Load Capacity: 17,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN24K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,325 lbs.
Load Capacity: 17,094 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN24K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,575 lbs.
Load Capacity: 16,781 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX30GN30K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 9,675 lbs.
Load Capacity: 25,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN30K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 9,899 lbs.
Load Capacity: 25,126 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN30K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 10,250 lbs.
Load Capacity: 24,688 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN30K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 10,890 lbs.
Load Capacity: 23,888 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN30K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,150 lbs.
Load Capacity: 23,563 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN30K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,508 lbs.
Load Capacity: 23,115 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN30K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,890 lbs.
Load Capacity: 22,638 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN30K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 12,350 lbs.
Load Capacity: 22,063 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

HTX 3D

360° View

Order Now

Standard Features

Features for “HTX30GN20K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,348 lbs.
Load Capacity: 13,315 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN20K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 8,780 lbs.
Load Capacity: 14,025 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN20K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 8,920 lbs.
Load Capacity: 13,850 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN20K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,060 lbs.
Load Capacity: 13,675 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN20K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,200 lbs.
Load Capacity: 13,500 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN20K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,340 lbs.
Load Capacity: 13,325 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN20K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,480 lbs.
Load Capacity: 13,150 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN20K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 20,000 lbs.
GAWR: 10,000 lbs.
Empty Weight: 9,620 lbs.
Load Capacity: 12,975, lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 10,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX30GN24K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,348 lbs.
Load Capacity: 17,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN24K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,550 lbs.
Load Capacity: 18,315 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN24K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,650 lbs.
Load Capacity: 17,938 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN24K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,750 lbs.
Load Capacity: 17,813 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN24K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 9,825 lbs.
Load Capacity: 17,719 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN24K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,075 lbs.
Load Capacity: 17,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN24K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,325 lbs.
Load Capacity: 17,094 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN24K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 24,000 lbs.
GAWR: 12,000 lbs.
Empty Weight: 10,575 lbs.
Load Capacity: 16,781 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 12,000 lb. Electric Brake Axles
10 Ply ST235/80R16 Dual Tires (3,520 lb. Rating)
16″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 6.5″
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX30GN30K”

Length: 30‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 9,675 lbs.
Load Capacity: 25,406 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX32GN30K”

Length: 32‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 9,899 lbs.
Load Capacity: 25,126 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX34GN30K”

Length: 34‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 10,250 lbs.
Load Capacity: 24,688 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX36GN30K”

Length: 36‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 10,890 lbs.
Load Capacity: 23,888 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX38GN30K”

Length: 38‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,150 lbs.
Load Capacity: 23,563 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX40GN30K”

Length: 40‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,508 lbs.
Load Capacity: 23,115 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX42GN30K”

Length: 42‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 11,890 lbs.
Load Capacity: 22,638 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

Features for “HTX44GN30K”

Length: 44‘
Width: 102″
Deck Height: 33“
GVWR: 30,000 lbs.
GAWR: 16,000 lbs.
Empty Weight: 12,350 lbs.
Load Capacity: 22,063 lbs.
Main Frame: Engineered Beam
Cross-Members: 3″ Channel on 16″ Centers
5″ Round Torque Tube
Side Perimeter: 5″ Channel
Rub Rail: 2″ Rub Rail With Spools and Stake Pockets
Fenders: 3/16″ Top Diamond Plate
11′ Hydraulic Tail Lift (10,000 lbs Lifting Capacity & 5,000 lbs Carrying Capacity)
Dual Cylinder Lift System
Pump: KTI 12V Hydraulic Pump
Tail: Knife Edge
Flooring: 2″ Treated Lumber Deck
Winch Ready (Winch Not Included)
Coupler: 2 5/16″ Adjustable
Jacks: Dual 10,000 lb. Side Wind Drop Leg Jacks
Tool Box: Bolt On Tool Box Between Risers
Suspension: HDSS Leaf Spring
Axles: 2 – 16,000 lb. Electric Brake Axles
18 Ply ST235/75R17.5 Dual Tires
17.5″ Black Mod Dual Steel Wheels
Bolt Pattern: 8 on 275mm
Safety Chains: 3/8″ G70 Chains
Spare Mount: Ready
Charger: 8 Amp 110 Volt Charger
Solar Panel: 12 Watt Solar Charging System
All Weather Proof Harness
Marker Lights: 3/4″ LED Bullet Lights
Rear Lights: 6″ Oval DOT Approved LED Lights
Paint: Powder Coated
Color: Midnight Black With Classic Orange Trim
5 Year Dexter Axle Warranty
3 Year Structural Warranty
1 Year Paint Warranty

HTX

Power

When the job demands maximum muscle and precision, the RawMaxx HTX steps in. Engineered for serious heavy-duty work, this gooseneck trailer comes in sizes up to 44′ long and packs up to 30,000 lb. GVWR, backed by dual 10K Dexter axles. Whether it’s machinery, construction equipment, or bulk loads, the HTX is built to carry more, safer, and smarter.

Its foundation starts with a 12″ I-beam main frame, reinforced with a 5″ torque tube and 3″ channel cross-members, giving the HTX unmatched stability across long spans. But the real game-changer? The 11′ hydraulic lift tail. With the push of a button, you get smooth, controlled loading and unloading without the need for bulky ramps. Efficiency meets brute strength in one seamless system.

Every detail has been designed for professionals: dual drop-leg jacks, EZ-load treated lumber deck, drive-over fenders, and welded D-rings that keep your load locked down. Safety never takes a back seat with G70 safety chains, a breakaway kit, and DOT-approved LED lighting.

And when the job calls for more, the HTX delivers with a full range of upgrades: axle packages up to 16K, electric/hydraulic brake systems, winches up to 17,500 lbs., underbody toolboxes, LED light bars, and even slide-track ratchet systems for ultimate load control.

The RawMaxx HTX isn’t just another hydraulic-tail trailer—it’s the pinnacle of power and efficiency, built for operators who demand performance on every haul.

HTX

Power

When the job demands maximum muscle and precision, the RawMaxx HTX steps in. Engineered for serious heavy-duty work, this gooseneck trailer comes in sizes up to 40′ long and packs a 20,000 lb. GVWR backed by dual 10K Dexter axles. Whether it’s machinery, construction equipment, or bulk loads, the HTX is built to carry more, safer, and smarter.

The RawMaxx HTX isn’t just another hydraulic-tail trailer—it’s the pinnacle of power and efficiency, built for operators who demand performance on every haul.
