G7X GN
Trailer Specs
Dimensions
Length:
20'
Width:
102"
Deck Height:
24"
Finish
Type:
Powder Coat
Prep:
Grit Blast
Standard Color:
Jet Black
Warranty
Axle:
5 Year Dexter
Trailer:
3 Year Structural / 1 Year Paint
Gooseneck
Coupler
Coupler:
2-5/16” Adjustable Ball Coupler
Jacks
Front Jacks:
2 Side Wind Drop Legs -10,000 lbs.
Tool Box
Tool Box:
Front Tool Box
Gooseneck
Tongue Length:
96"
Safety System
Safety Chains:
3/8" G70 Safety Chains
Breakaway System:
Electric Breakaway Kit
Reflective Tape:
3M DOT Compliant Reflective Tape
Frame
Side
Side Perimeter:
3/16" Formed Thread Plate
Rub Rail:
2" x 3/8" Flat Bar
Stake Pockets:
3-7/8" x 1-13/16" (ID)
Chain Spool:
1 5/8" OD
Fenders:
12G Steel Fenders
Frame
Frame:
8" x 13 lb. I-beam Frame
Cross-Members:
3" Channel / 12" Spacings
Gravity Tilt Deck
Front Deck:
4' Stationary Deck
Spare Tire Compartment:
In Stationary Deck
Deck:
16' Tilt Deck
Tilt System:
Gravity Up / Down
Tilt Angle:
11°
Flooring:
2” Treated Lumber Deck
D-Rings:
4 D-Rings (Welded Inside Fenders)
Swivel D-Rings:
2 D-Rings (Located at Front Corners)
Running Gear
Tires
Type:
Radial Tires
Size:
ST235/80R16
Ply:
10 Ply
Rating:
3,520 lbs.
Rims:
16” Black Mod Wheels
Bolt Pattern:
8 on 6.5”
Suspension
Axle Type:
Torsion
Axles:
2
Rating:
7,000 lbs.
Brakes:
Electric
Type:
Torflex
Electrical & Lighting
Wiring
Front Plug:
7 - Way Front Plug
Frame Wiring:
All Weather Wiring Harness
Lighting
Side Markers:
3/4" LED Bullet Lights
Rear Lights:
DOT Approved LED Lights
Available Upgrades
Tire Options
Spare Tire Options
Winch Options
Trailer Specs
Dimensions
Length:
22'
Width:
102"
Deck Height:
24"
Finish
Type:
Powder Coat
Prep:
Grit Blast
Standard Color:
Jet Black
Warranty
Axle:
5 Year Dexter
Trailer:
3 Year Structural / 1 Year Paint
Gooseneck
Coupler
Coupler:
2-5/16” Adjustable Ball Coupler
Jacks
Front Jacks:
2 Side Wind Drop Legs -10,000 lbs.
Tool Box
Tool Box:
Front Tool Box
Gooseneck
Tongue Length:
96"
Safety System
Safety Chains:
3/8" G70 Safety Chains
Breakaway System:
Electric Breakaway Kit
Reflective Tape:
3M DOT Compliant Reflective Tape
Frame
Side
Side Perimeter:
3/16" Formed Thread Plate
Rub Rail:
2" x 3/8" Flat Bar
Stake Pockets:
3-7/8" x 1-13/16" (ID)
Chain Spool:
1 5/8" OD
Fenders:
12G Steel Fenders
Frame
Frame:
8" x 13 lb. I-beam Frame
Cross-Members:
3" Channel / 12" Spacings
Gravity Tilt Deck
Front Deck:
4' Stationary Deck
Spare Tire Compartment:
In Stationary Deck
Deck:
16' Tilt Deck
Tilt System:
Gravity Up / Down
Tilt Angle:
11°
Flooring:
2” Treated Lumber Deck
D-Rings:
4 D-Rings (Welded Inside Fenders)
Swivel D-Rings:
2 D-Rings (Located at Front Corners)
Running Gear
Tires
Type:
Radial Tires
Size:
ST235/80R16
Ply:
10 Ply
Rating:
3,520 lbs.
Rims:
16” Black Mod Wheels
Bolt Pattern:
8 on 6.5”
Suspension
Axle Type:
Torsion
Axles:
2
Rating:
7,000 lbs.
Brakes:
Electric
Type:
Torflex
Electrical & Lighting
Wiring
Front Plug:
7 - Way Front Plug
Frame Wiring:
All Weather Wiring Harness
Lighting
Side Markers:
3/4" LED Bullet Lights
Rear Lights:
DOT Approved LED Lights
Available Upgrades
Tire Options
Spare Tire Options
Winch Options
Trailer Specs
Dimensions
Length:
24'
Width:
102"
Deck Height:
24"
Finish
Type:
Powder Coat
Prep:
Grit Blast
Standard Color:
Jet Black
Warranty
Axle:
5 Year Dexter
Trailer:
3 Year Structural / 1 Year Paint
Gooseneck
Coupler
Coupler:
2-5/16” Adjustable Ball Coupler
Jacks
Front Jacks:
2 Side Wind Drop Legs -10,000 lbs.
Tool Box
Tool Box:
Front Tool Box
Gooseneck
Tongue Length:
96"
Safety System
Safety Chains:
3/8" G70 Safety Chains
Breakaway System:
Electric Breakaway Kit
Reflective Tape:
3M DOT Compliant Reflective Tape
Frame
Side
Side Perimeter:
3/16" Formed Thread Plate
Rub Rail:
2" x 3/8" Flat Bar
Stake Pockets:
3-7/8" x 1-13/16" (ID)
Chain Spool:
1 5/8" OD
Fenders:
12G Steel Fenders
Frame
Frame:
8" x 13 lb. I-beam Frame
Cross-Members:
3" Channel / 12" Spacings
Gravity Tilt Deck
Front Deck:
4' Stationary Deck
Spare Tire Compartment:
In Stationary Deck
Deck:
16' Tilt Deck
Tilt System:
Gravity Up / Down
Tilt Angle:
11°
Flooring:
2” Treated Lumber Deck
D-Rings:
4 D-Rings (Welded Inside Fenders)
Swivel D-Rings:
2 D-Rings (Located at Front Corners)
Running Gear
Tires
Type:
Radial Tires
Size:
ST235/80R16
Ply:
10 Ply
Rating:
3,520 lbs.
Rims:
16” Black Mod Wheels
Bolt Pattern:
8 on 6.5”
Suspension
Axle Type:
Torsion
Axles:
2
Rating:
7,000 lbs.
Brakes:
Electric
Type:
Torflex
Electrical & Lighting
Wiring
Front Plug:
7 - Way Front Plug
Frame Wiring:
All Weather Wiring Harness
Lighting
Side Markers:
3/4" LED Bullet Lights
Rear Lights:
DOT Approved LED Lights
Available Upgrades
Tire Options
Spare Tire Options
Winch Options
Meet the new face of gravity
The G7X GN is designed for versatility and durability. Making it one of the toughest equipment/car haulers on the market. A bold statement that we can back up with the 8″ x 13lb. I-beam frame, higher profile and only 11 degree tilt angle design. The worst road conditions will not stop you from getting you to where you need to go. Allowing you to transport heavy equipment and cars with ease, no matter where your job takes you.
